AD3XG CETOP 3 electrically controlled ATEX all-or-nothing distributor Valve
- Brand: Dana Brevini Aron
- Product Code: AD3XG
- Availability: In Stock
0.00€
- Ex Tax: 0.00€
PLEASE ASK FOR PRICE!
AD3XG
Product or component category: Distribution valves | Hydraulic distributors
CETOP 3 electrically controlled ATEX all-or-nothing distributor
| Max pressure (Ports P/A/B) | 350 bars |
| Max pressure (T port) | 250 bars |
| Max flow rate | 80 l/min |
| Max. excitation frequency | 3 Hz |
| Excitement | 100% ED |
| Hydraulic fluids | mineral oils DIN 51524 |
| Fluid viscosity | 10 ÷ 500 mm2/s |
| Fluid temperature | -30°C ÷ 70°C |
| Room temperature (T4) | -40°C ÷ 80°C |
| Room temperature (T6) | -40°C ÷ 50°C |
| Maximum contamination level | class 10 according to NAS 1638 with filter ß25≥75 |
| Weight (one spool) | 3 Kg |
| Weight (two spools) | 5 kg |
